Summary

The GEPRC team has redesigned the Vapor series for optimal compatibility with the  O4 Air Unit Pro VTX.

New aluminum lens components and shock-absorbing silicone reduce vibrations, while the sharp new side panels give it a bold, mech-inspired look. The  O4 Air Unit Pro's larger CMOS sensor enhances image detail and sensitivity, and the GEPRC-tuned PID settings ensure a smooth and immersive flight experience.

Available in two models, Wide X and DC, to suit different flight needs.

Feature

1. O4 Air Unit Pro features a powerful CMOS sensor for improved image clarity and enhanced light sensitivity.

2. CNC aluminum lens housing for a durable, bold design.

3. GEPRC SPEEDX2 E-series motors for smooth, powerful performance.

4. Front lip design provides extra lens protection for confident flying.

5. Wider 5mm carbon fiber arms for increased durability and a sleek build.

Specifications

• Model: Vapor-D6 O4 Pro

• Frame: GEP-Vapor-D6 O4 Pro frame

• Wheelbase: 274.60 mm

• Top Plate: 2.0 mm

• Middle Plate: 2.0 mm

• Bottom Plate: 2.5 mm

• Arm Thickness: 5.0 mm

• FC: GEP-F722-HD v2

• MCU: STM32F722

• Gyro: ICM42688-P(SPI)

• Barometer: YES

• OSD: Betaflight OSD w/AT7456E

• ESC: TAKER H60_BLS 60A 4IN1 ESC

• VTX:  O4 Air Unit Pro Transmission Module

• Camera:  O4 Air Unit Pro Transmission Module

• Antenna:  O4 Air Unit Pro Antenna

• Connector: XT60

• Optional GPS: GEP-M10 GPS

• 6-inch Motor: GEPRC SPEEDX2 2407E 1750KV

• 6-inch Propeller: HQprop 6X3.5X3

• Vapor-D6 O4 Pro PNP  Version Weight: 465 g±5g

• Receiver: PNP/GEPRC ELRS24/TBS Nano RX

• Recommended Battery: 6S LiPo1500mAh – 2000mAh

• Flight Time: 14-19 min

Includes

The spare screws include
